5000 LPD Overhead Tank Filter

5000-LPD-Overhead-Tank-Filter
5000 LPD Overhead Tank Filter
Application

Applications of 5000 LPD Overhead Tank Filter :

Homes
Hospitals
Hotels
Schools
Restaurants

We manufacture high-quality 5000 LPD Overhead Tank Filters in Chennai. Our filters are ideal for use in hotels, restaurants, homes, and schools.

Specification

Specification of 5000 LPD Overhead Tank Filter :

S.NO Specifications Details of EquipmentQuantity
1 Dual Media Filter
Supply, Erection and Commissioning of Pressure DMF with following Specifications:
Vessel :355mm Dia  X 1372 Height
Design Pressure : 10.0 Kg / Cm²
Working Pressure : 3.0 Kg / Cm²
Filter Media :  IR OT1, Silex.
Valves : Multi-Port Valves: 25NB (Manual)
Accessories : Frontal pipes, Values, Pressure Gauge fitted to give indication pressure drop through filter		Pentair/
 Clean Water		1 Set.
2 Filter Feed pump
Capacity 1500LPH, Head- 28 Metres;
 Motor– 1  hp, Type- Mono-bloc.		Kirloskar/ Suguna/DAB
Equivalent		 1 no
Client scope
3 Pipe Works
Interconnecting Pipes & Fittings for lines. Water aeration system specially designed pipes.		 CPVC / UPVC
Client scope
Highlights
  1. The 5000 LPD Overhead Tank Filtration system is easy to install without disrupting your existing pipelines, simply by bypassing to your overhead tank.
  2. It ensures crystal-clear water by effectively removing even the tiniest iron particles.
  3. The valves are made in Germany, featuring an inbuilt ceramic disc for superior performance.
  4. The filtration cylinder vessels are crafted from high-quality Pentair FRP, a top-tier brand for FRP vessels.
  5. The filter media used for iron removal lasts for 10 to 15 years without requiring replacement.
  6. In essence, the WATERSPARKS Iron Removal Filtration System is a “ONE-TIME SOLUTION” for your water quality needs.
Description

The 5000 LPD Overhead Tank Filter system effectively filters out sediment impurities such as sand, silt, dust, chlorine, and more.

Even metro or panchayat water, which we receive from reserved rainwater sources, can be contaminated.

Using this contaminated water can lead to harmful diseases like flu, viral infections, and more.

By passing the water through the Overhead Tank Filter, it removes these contaminants and ensures that only pure water is passed to the overhead tank.
